| Systen Specifications | ||||
|---|---|---|---|---|
| System Model | CT1-5 | CT1-10 | CT1-15 | CT1-20 |
| Battery Module Model | BE-LFP-100Ah-P | BE-LFP-100Ah-P | BE-LFP-100Ah-P | BE-LFP-100Ah-P |
| Number of Battery Enclosures | 1 | 2 | 3 | 4（Supports parallel scalability up to 16 units） |
| Energy Storage Capacity(kWh) | 5 | 10 | 15 | 20 |
| Voltage Range(V) | 44.8 - 57.6 | 44.8 - 57.6 | 44.8 - 57.6 | 44.8 - 57.6 |
| Standard Charge/Discharge Current(A) | 50/100 | 100/100 | 100/100 | 100/100 |
| Maximum Charge/Discharge Current(A) | 100/100 | 110/110 | 110/110 | 110/110 |
| Communication - Display Method | Battery Level Indicator | Battery Level Indicator | Battery Level Indicator | Battery Level Indicator |
| Communication - Communication Methods | RS485、Ethernet（Remote Maintenance） | RS485、Ethernet（Remote Maintenance） | RS485、Ethernet（Remote Maintenance） | RS485、Ethernet（Remote Maintenance） |
| General Specifications - System Dimensions(mm) | 392×591×198 | 392×591×391 | 392×591×584 | 392×591×777 |
| General Specifications - System Weight(kg) | 45 | 93 | 140 | 186 |
| General Specifications - Installation Method | Stackable | Stackable | Stackable | Stackable |
| General Specifications - Protection Rating | IP22 | IP22 | IP22 | IP22 |
| General Specifications - Battery Type | LFP | LFP | LFP | LFP |
| General Specifications - Depth of Discharge (%) | 95 | 95 | 95 | 95 |
| General Specifications - Cycle Life (25℃) | ≤6000 | ≤6000 | ≤6000 | ≤6000 |
| General Specifications - Standard Inverter | Grid-Tie Inverter with Standard Communication Protocol | Grid-Tie Inverter with Standard Communication Protocol | Grid-Tie Inverter with Standard Communication Protocol | Grid-Tie Inverter with Standard Communication Protocol |
| Environmental Parameters - Operating Temperature (℃) | charge: 0~45; discharge: -20~45 | charge: 0~45; discharge: -20~45 | charge: 0~45; discharge: -20~45 | charge: 0~45; discharge: -20~45 |
| Environmental Parameters - Relative Humidity (%) | 5~95（No Condensation） | 5~95（No Condensation） | 5~95（No Condensation） | 5~95（No Condensation） |
| Environmental Parameters - Operating Altitude(m) | < 2000 | < 2000 | < 2000 | < 2000 |
| Certifications - Battery System Certification | IEC 62619、UN 38.3、CE-EMC、IEC 60730-1、VDE 2510-50、IEC 62477、UL9540A、UL1973、FCC | IEC 62619、UN 38.3、CE-EMC、IEC 60730-1、VDE 2510-50、IEC 62477、UL9540A、UL1973、FCC | IEC 62619、UN 38.3、CE-EMC、IEC 60730-1、VDE 2510-50、IEC 62477、UL9540A、UL1973、FCC | IEC 62619、UN 38.3、CE-EMC、IEC 60730-1、VDE 2510-50、IEC 62477、UL9540A、UL1973、FCC |
